For live sound productions, large facility installations, and broadcast environments, the Focusrite RedNet MP8R combines the stellar sound quality you want with the redundant reliability your system needs. The RedNet MP8R essentially takes the proven RedNet 4 interface, equips it with updated mic preamp technology, and adds redundant power supplies and networking for maximum system reliability. We're mighty impressed with these preamps at Music Experience, with impressive transparency and headroom that hold up well with virtually any sound source. When you need to add outstanding mic inputs to your RedNet network, and you need the peace of mind that redundant power and networking provide, you need the Focusrite RedNet MP8R.

Focusrite RedNet MP8R at a Glance:

• RedNet audio interface with redundant power supplies and networking for maximum reliability
• Ideal for live sound, broadcast, and large installations
• 8 high-quality Focusrite mic preamps, remote-controllable from any computer on the RedNet network
• Each preamp channel provides two channels on the network for easy signal splits
• Redundant networking via two Neutrik Ethercon locking network connectors
• Redundant power supplies for maximum system reliability in any environment
• Free Brainworx bx_console re-creation of Focusrite's ISA 110 and ISA 130 modules
• 3-year warranty

Amazing mic preamps designed for live performance and broadcast

Focusrite went back to the drawing board with the RedNet MP8R to create an amazing set of preamps, now with up to +28dBu input level, -20dB pad, phase invert, high/low impedance modes, and even better common mode rejection. With plenty of headroom, virtually no noise, and well-balanced response across the entire gain range, the RedNet MP8R exceeds the expectations of live sound engineers.

Easy signal splits with DSP gain tracking

While the RedNet MP8R provides eight stellar mic inputs for your live sound system, it actually shows up as a 16-channel source on your Dante network. Each mic input is split into two - one direct feed that responds to that channel's gain control, and a second feed with DSP gain tracking. The DSP maintains a consistent output level for the second signal, irrespective of the analog mic gain setting. It's an easy way to send a high-quality audio split to a second engineer for monitor mixing or broadcast.

Convenient remote control via the RedNet network

Because you'll be using the RedNet MP8R as a component of a large-scale system, Focusrite makes it easy for you to control and re-route signals via a simple software control panel. No matter where you are in your facility, if you have access to the RedNet network from your computer you'll have complete control over every RedNet device connected to that network.

What Focusrite Says...

RedNet MP8R is an 8-channel remote-controlled microphone preamplifier and A/D for the Dante audio-over-IP network. Developed from the RedNet 4 studio remote-controlled microphone preamp, and incorporating input from leading live sound practitioners during its development, the MP8R provides a wealth of features that make it particularly applicable to the live sound/recording and broadcast environments, where reliability is paramount. Dual Ethernet ports are provided, with several operating modes including daisy-chaining and redundancy confirmed by front-panel indicators. Two separate power supplies with fault detection capability are included, with separate power input sockets on the rear panel. Power failure is indicated both remotely and on the front panel. The MP8R features a rugged, roadworthy exterior and maximum internal build quality. In addition, the MP8R offers a compact 1U rack-mount form factor. The MP8R preamps represent the latest iteration of Focusrite's award-winning mic pre designs, with a pedigree that stretches back to the original Focusrite products of the mid-1980s. Fully keeping pace with the latest developments in audio technology, today's Focusrite preamps offer lower noise and great dynamic range than ever before. The preamps in the MP8R offer an increased maximum input level of 28dBu, plus a 20dB pad, high-pass filter, polarity inversion and phantom power. Each preamp has a dual input impedance of 10k½ or 2.4k½, allowing flexibility when running multiple mic pres in parallel. A particular feature of the MP8R targeted at the live sound field is its gain tracking ability. The unit appears as a 16-channel device on the network, the first eight channels being direct preamp feeds, while the remaining eight are automatically DSP level-compensated outputs sourced from the first eight. This architecture allows "splits" — such as monitor/FOH — to be set up in the digital domain, permitting one engineer to control the analogue mic gain while a second receives an output level that is constant irrespective of the analogue mic gain setting. The preamps may be controlled in a variety of ways, including via the RedNet Control software package, Pro Tools and MIDI, and OCA (Open Control Architecture); in addition, the preamps can be operated from the MP8R front panel, where 6-segment level metering, numeric gain display and other indicators provide comprehensive monitoring of the unit's operation. Following the mic pres are eight channels of Focusrite's legendary high-precision A/D converters, operating at up to 192kHz/24-bit with minimum latency and offering class-leading dynamic range and overall performance. Like the totality of the RedNet range, the MP8R interoperates seamlessly and fully with any other Dante audio-over-IP network components and infrastructure. Patching and interconnection can be managed with the Dante control software, while RedNet Control offers comprehensive remote mic pre operation.

8-channel remote-controlled mic pre with A/D and Dante audio-over-IP networking

Eight remote-controlled Focusrite mic preamps and precision A/D conversion at up to 192kHz provide a compact, rugged interface compatible with any Dante network hardware and infrastructureR

Power and Ethernet redundancy

MP8R is ideal for critical path applications, with dual power supplies that include local and remote status indication, and dual Ethernet ports.

Tailored for the Live Sound environment

MP8R includes rugged road-worthy construction, high build quality and built-in redundancy for power and network connections.

Comprehensive indicators tell status at a glance

Two power LEDs (one per PSU) are provided, along with remote indication of PSU status. 6-segment metering provides useful level indication for each channel and function indicators indicate individual preamp settings. An OLED display indicates input gain and system information.

Flexible input capability

Including a new, enhanced input level capability, MP8R mic pres include dual input impedance to deliver maximum performance in a variety of configurations.

Remote or local control of mic pre parameters

In addition to mic gain, MP8R mic pres offer 20dB Pad, High-pass filter and polarity inversion, all controllable remotely or from the front panel.

Multiple remote control possibilities

MP8R has full front panel control, but can most effectively be operated via RedNet Control software on a host computer, or directly via Pro Tools or MIDI, or OCA (Open Control Architecture). RedNet Control software allows full routing and control from your audio computer system via a software control panel — without hardware patching.

Best-in-class Focusrite A/D conversion

The eight mic pres are followed by precision low-latency conversion at up to 24-bit 192kHz, offering best-in-class dynamic range.

Comprehensive indicators tell status at a glance

Two power LEDs (one per PSU) are provided, along with remote indication of PSU status. 6-segment metering provides useful level indication for each channel and function indicators indicate individual preamp settings. An OLED display indicates input gain and system information.

Separate outputs with automatic gain compensation

Each preamp provides two outputs: one direct and the other that is automatically gain-compensated to deliver a constant level. This gain tracking capability allows "splits", such as FOH/monitor, to be carried out in the digital domain, permitting one engineer to control the analogue mic gain while a second receives a gain-compensated output.

Superb road-worthy build quality

Designed for life on the road, MP8R features etherCON locking Ethernet connectors, highest quality Neutrik XLR connectors and locking power input sockets. The compact 1U all-metal enclosure is ruggedly constructed and redundant power and Ethernet facilities maximise reliability in the field.

8-Channel remote-controlled mic pre with dual PSUs

RedNet MP8R is a 1U, eight-channel remote-controlled mic pre and A-D interface for any Dante™ audio-over-IP network. Featuring network and power supply redundancy, RedNet MP8R is the ideal choice for providing mic pres in many critical-path applications, whether in Post Production, Broadcast, Live Sound or the Recording Studio. RedNet MP8R was designed in direct response to requests from clients in Live Sound and Broadcast looking for a high-quality remote controlled mic pre coupled with high performance A-D conversion. The result is a preamp with high dynamic range, flat frequency response, and excellent common-mode gain performance. The unique automatic gain compensation feature allows for a variety of flexible workflows; each mic pre feeds a pair of network transmitters, – one directly fed by the mic pre, the other fed through automatically compensated DSP – making mic pre sharing very simple. Front panel level indication is provided through 6-segment LED meters, while an OLED display indicates input gain and other system information.

The Focusrite Studio Console reborn in your DAW

The Focusrite Studio Console defined countless hits of the 80s and 90s, thanks in large part to its ISA 110 Equaliser and ISA 130 Dynamics Modules. Brainworx's bx_console Focusrite plug-in brings you stunningly accurate emulations of both in a single plug-in, perfectly capturing the famously warm, open sound of two of the most revered pieces of studio hardware ever made.

Enjoy 3 years of warranty
