The elysia xpector is a dual Class A headphone amplifier and monitor controller designed for professional recording, mixing, and audiophile listening. Housed in elysia’s rugged and compact qube chassis with 12 audio connections on the back plate, the xpector provides flexible monitoring solutions for engineers and artists alike. Its customizable engineer and artist feeds allow each user to hear exactly what they need, while stereo Direct and DAW inputs feed signals to the corresponding front-panel mix controllers. Daisy-chain multiple units for latency-free custom mixes, or loop in mic preamps and feed signals to your audio interface. With its versatility and sonic excellence, the xpector ensures smooth-running sessions and stellar results.
The xpector features two high-end headphone amplifiers, providing mirrored engineer and artist feeds with customizable parameters for each. Vocalists and instrumentalists can have entirely different mixes, ensuring optimal performance. The artist feed includes a 2-band shelving equalizer for quick tone adjustments, helping coax the best performance from singers and other musicians.
Send the xpector’s balanced XLR outputs to powered monitor speakers for accurate monitoring without headphones. One press of the speaker button activates speakers while muting engineer headphones. Use the Trim control to adjust volume differences between headphones and speakers, and the Swap switch to select which output serves as the reference for trim adjustments.
The engineer feed includes advanced monitoring features such as mono, M-S (mid-side), and solo modes for left and right channels, all controlled via an intuitive rotary switch. Connect up to two stereo inputs and mix them independently, with separate mix controllers for each signal. The DAW control lets you monitor the direct signal or blend input signals, while the level control adjusts headphone volume. Class A circuitry and a low-noise power supply ensure exceptional audio quality across all configurations.
Designed and manufactured in Nettetal, Germany, elysia products combine cutting-edge audio engineering with high-quality military-grade components. The xpector delivers sophisticated, reliable solutions for recording, mixing, mastering, broadcast, and live sound applications, providing many years of trouble-free service and professional-grade performance.
The elysia xpector is a state-of-the-art dual headphone amplifier designed for artists and producers seeking precise, professional monitoring. Portable and housed in the versatile qube chassis, it offers 12 audio connections, mirrored engineer and artist headphone outputs, and balanced XLR speaker outputs. Whether used in home studios or professional environments, the xpector ensures superior three-dimensional stereo imaging and exceptional audio quality for every session.
The xpector combines ultraportable design with advanced connectivity. Its custom backplate accommodates dual headphone outputs, DAW and Direct inputs, and Loop outputs for daisy-chaining multiple units or feeding signals to an interface. This versatility makes it suitable for both home enthusiasts and professional studios, providing endless routing possibilities for artists and engineers alike.
At the core of the xpector is a super-low-noise internal power supply, ensuring the purest possible audio signal. With minimal interference and maximum clarity, you can focus entirely on music production, recording, or mixing, knowing the signal path is pristine.
As part of the qube series, the xpector brings professional analog audio processing wherever you need it. Compact and portable, it allows you to record, monitor, and mix with professional-grade hardware whether in the studio, at home, or on the go.
The elysia xpector is more than a headphone amplifier—it’s an essential tool for professional artists and producers. Its dual outputs, advanced monitoring features, and precise audio fidelity make it perfect for critical sessions, intricate mixes, or sound design work. Upgrade your studio setup with the xpector and experience unparalleled headphone amplification and monitoring precision, bringing your audio projects to life with complete clarity and control.
| Type | Dual Headphone Amp |
|---|---|
| Output Channels | 2 x Stereo (Engineer, Artist) |
| Analog Inputs | 2 x 1/4" TRS (Direct L, R), 2 x 1/4" TRS (DAW L, R) |
| Analog Outputs | 2 x 1/4" TRS (Direct L, R), 2 x 1/4" TRS (DAW L, R), 2 x XLR (Speaker L, R) |
| Headphones | 2 x 1/4" TRS (Artist), 2 x 1/4" TRS (Engineer) |
| Controls per Channel | Level, DAW, Direct |
| Form Factor | Desktop |
| Power Supply | 18V 1A DC power supply (included) |
| Height | 8.4" |
| Width | 5.39" |
| Depth | 4.1" |
| Weight | 3.17 lbs. |
| Manufacturer Part Number | xpector |
